StreamOps Control Plane

Ingest, transcode, record and deliver without command-line assembly.

Operate contribution, GPU encoding, DVB multiplexing, studio recording, storage and network delivery from one broadcast control plane.

Request StreamOps demo Browse modules

SDI / IP

Inputs

GPU

Processing

DVB / OTT

Outputs

Ingest

DeckLink / AJA · SRT · RTMP · UDP/RTP · RTSP · VOD

Process

FFmpeg core · NVENC · QSV · AMF · PSI/SI · recording

Deliver

DVB MPTS · HLS/DASH · SRT · RTMP · storage · devices

Operational modules

Open the tool for the media job.

Module pages no longer reuse a generic screenshot. Where a matching interface exists, that interface is shown. Where it does not, the page uses a purpose-built technical visualization instead.

Live TV Channel Composer & Transcoding Grid

Ingest SDI, HDMI, SRT, RTMP, RTSP, HTTP-TS, UDP/RTP and VOD feeds to encode pristine broadcast and OTT linear television channels with hardware GPU acceleration.

Enterprise DVB MPTS Multiplexer Engine

Combine multiple independent channels into standards-compliant Multi-Program Transport Streams with automatic DVB PSI/SI generation, collision-free PID mapping and CBR null-packet stuffing.

Professional Studio Ingest & Master Recording

Capture uncompressed 10-bit 4:2:2 masters and broadcast MXF files from Blackmagic DeckLink SDI/HDMI cards and IP streams with zero-frame-loss recording.

Distributed Storage, Network Shares & Cloud Sync

Store, browse and distribute recorded broadcast masters across local NVMe storage, enterprise SMB/CIFS SANs, embedded FTP and Amazon S3.

Live Ingest Server & Stream Hijack Security

Hardened RTMP/RTMPS and SRT ingest gateway designed to prevent unauthorized broadcast access and stream piracy.

External Studio Automation & TCP Control Protocol

Integrate StreamOps with broadcast television studio automation, vision switchers and physical controllers via low-latency TCP socket protocol (Port 9999).

Transcode Studio & Batch VOD Processing

Offline parallel GPU transcoding engine converting high-bitrate studio masters into web, broadcast and mobile distribution profiles.

VOD Playout & Virtual Linear Channels

Convert static video libraries into scheduled 24/7 linear broadcast feeds with seamless looping and dynamic HLS/DASH packaging.

Carrier Networking & High Availability

Operate high-throughput broadcast networks with 802.3ad LACP bonding, 802.1Q VLANs, IGMPv3 SSM and policy-based routing.

Real-Time Hardware Telemetry & SNMP Alarms

Prevent broadcast failures before they happen with GPU/VRAM telemetry, per-core CPU load, thermal monitoring and SNMP traps.

DecodX Fleet Middleware & STB Ecosystem

Management plane for operating proprietary hardware decoders and Android TV Set-Top Box fleets with remote control and OTA updates.

Enterprise Security, Role-Based Access & Audit Logging

Satisfy strict enterprise IT security audits with granular RBAC, immutable audit logging and Ed25519 cryptographic licensing.

Infrastructure depth

Broadcast protocols without command-line assembly.

Keep encoding, multiplexing, recording and network operations visible while retaining the protocol depth expected in a headend or studio environment.

NVMe · SMB/CIFS · S3 / MinIO

RBAC · audit · signed licensing

LACP · VLAN · IGMPv3 SSM

Ingest protocols

SDI (HD/3G/6G/12G), HDMI 2.0/2.1, SRT (Caller/Listener), RTMP/RTMPS, UDP/RTP Multicast (SPTS/MPTS), HTTP-TS, HLS, DASH, RTSP

Egress protocols

DVB UDP Multicast (pkt_size=1316), RTP Multicast, SRT (Caller/Listener), RTMP/RTMPS, HLS (Adaptive Bitrate), MPEG-DASH, HTTP-TS

Video codecs

H.264 (AVC Baseline/Main/High), H.265 (HEVC Main/Main10), MPEG-2 Broadcast (4:2:0 & 4:2:2), VP9, AV1, Uncompressed v210 (10-bit)

Audio codecs

AAC (LC/HE), MP2 (MPEG-1 Audio Layer II), AC3 (Dolby Digital), EAC3 (Dolby Digital Plus), Opus, MP3, PCM 16-bit / 24-bit (up to 8 channels)

Hardware acceleration

NVIDIA NVENC / NVDEC (Pascal through Ada Lovelace / Hopper / Blackwell), Intel QuickSync (QSV), AMD AMF, Apple VideoToolbox

Capture hardware

Blackmagic Design DeckLink Series, Intensity Pro 4K, UltraStudio, AJA Video Systems, Magewell, DirectShow, V4L2

DVB specifications

ISO/IEC 13818-1 (MPEG-2 TS), EN 300 468 (DVB SI), TR 101 290 (Priority 1/2 compliance), CBR null-stuffing (PID 0x1FFF)

Storage & networking

Local NVMe/SSD, SMB v2/v3, NFS, Embedded Secure FTP/FTPS, Amazon S3, MinIO, IEEE 802.3ad LACP, IEEE 802.1Q VLAN, IGMPv3 SSM

Automation & NOC

Dedicated TCP Socket Server (Port 9999), RESTful HTTP API, WebSocket Live Events, SNMP v2c/v3 Traps

StreamOps deployment

Build the media path around your headend or studio.

Share your input protocols, channel count, encoding ladders, DVB requirements, recording formats, storage targets and network topology. We’ll map a StreamOps deployment.

Request demo Talk to engineering
